Suppliers and Manufacturer of Stainless Steel AL6XN Forged Fittings & Forged Socket Weld Fittings, which are non-magnetic within the annealed condition. Stainless Steel UNS N08367 Forged Threaded Fittings have terrific mechanical homes. They are substantially used for leak evidence repairing of piping or tubing systems, that is used for conveying diverse liquid. Our Stainless steel AL6XN Forged Fittings are widely accepted for their outstanding resisting properties and toughness. It is excellent working in several corrosive conditions and reducing environments. In addition, it is cost-effective than other expensive nickel-based alloys. We are amid the most prominent enterprises keenly affianced in offering a board collection of AL-6XN Forged Fittings, AL6XN Socket weld Fittings and Alloy AL6XN Threaded Fittings. It is getting used in lots of aerospace airframe and engine additives and additionally foremost non-aerospace programs within the marine, offshore and electricity era industries in particular.
Alloy AL6XN Forged Socket Weld Fittings also are utilized in Instruments / instrumentation; Caustic environments; Corrosive environments; Pins; Pulleys; Bearings, Shafts, Sleeves; Architectural; and more. Along with this, the best fabric composition makes especially resistive to corrosive environment. We are supplier and exporter of top class grade SS AL-6XN Forged Fitting that have extensive applications in cement production, chemical industries and petrochemical industries. We cater to the needs of several utility regions in engineering and creation industries. Made from qualitative grades of steel, they’re broadly acclaimed for sturdiness, corrosion resistance and excessive tolerance requirements. These SS Alloy Al6XN Forged Socket Weld Fittings avail types like tee, cross, nipple, elbow, pipe end caps, coupling, reducing nipple and pipe nipple are widely acknowledged for reliability, durability, high strength and corrosion resistance. Stainless Steel AL6XN Fitting offers high corrosion resistance and a greater working range than alloy. It is utilized in programs which are as much as four hundred ranges Celsius. It has progressed excessive temperature power and indicates terrific resistance to pitting.
| Specifications | ASTM A182/ ASME SA182 |
|---|---|
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Types | Socketweld Fittings, Screwed-Threaded Fittings |
| Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Thread | NPT, BSPT, BSPP |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| STANDARD | UNS |
| AL6XN | N08367 |
| Mo | Ni | Cr | S | Cu |
| 6.00-7.00 | 23.5-25.5 | 20.00-22.00 | 0.03 Max | 0.75 Max |
| Mn | C | Si | N | P |
| 2.0 Max | 0.03 Max | 1.00 Max | 0.18-0.25 | .040 Max |
| .2% Yield Strength, psi | Elongation in 2″, percent | Ult. Tensile Strength, psi |
| 142,000 | 36 | 218,000 |
| 107,000 | 49 | 196,000 |
| – | – | – |
| 53,000 | 47 | 108,000 |
| 49,400 | 47 | 99,900 |
| 40,400 | 46 | 903,000 |
| 36,300 | 47 | 86,000 |
| 36,000 | 48 | 87,000 |
